| Quantity: | |
|---|---|
Specification:
Uses: Suitable for the sealing of injection liquid
Packing: Inner packing is double-layer high-density polyethylene bag,and the outer packing is corrugated box.
Industry Standard: YBB00042005-2015;
| ITEM | Spec | Main feature | Main size(mm) | |||
| Head Dia | Plug Dia | Height | Head thickness | |||
| 1 | 20-V | One needled hole, Four points | 18.8±0.2 | 13.2±0.1 | 7.0±0.3 | 3.3±0.2 |
| 2 | 20-A | Double needled circles | 18.8±0.2 | 13.2±0.1 | 8.8±0.3 | 3.3±0.2 |
| 3 | 24-B | Three arcs, Two needled holes | 23.9±0.3 | 13.9±0.2 | 10.2±0.4 | 3.8±0.25 |
| 4 | 26-B | Three arcs, Two needled holes | 25.5±0.3 | 15.5±0.2 | 10.0±0.4 | 3.8±0.25 |
| 5 | 28-B | Single circle, One needled hole | 27.1±0.3 | 17.8±0.2 | 10.2±0.4 | 3.4±0.25 |
| 6 | 28-B3 | Single needled circle, Three rays | 26.9±0.3 | 18.0±0.2 | 11.8±0.4 | 3.8±0.25 |
| 7 | 32-A | Four needled holes, Three arcs, Four rays | 30.8±0.3 | 23.6±0.2 | 12.2±0.4 | 4.0±0.25 |
| 8 | 32-A1 | Four needled holes, Three arcs, Four rays | 30.8±0.3 | 24.0±0.2 | 16.0±0.4 | 5.0±0.25 |
| 9 | 34-A | One needled hole, Four rays | 32.6±0.3 | 26.5±0.2 | 14.5±0.3 | 4.3±0.25 |
